| DIMENSI |
| Panjang |
6,600 mm |
|
| Lebar
| 2,495 mm |
| Tinggi |
2,925 mm |
| Jarak Sumbu |
3,265+1,370 [WB1+WB2] mm |
| Julur Depan |
715 mm |
| Julur Belakang |
1,250 mm |
| Jarak Terendah ke Tanah |
265 mm |
| Jarak Depan |
2,060 mm |
| Jarak Belakang |
1,850 mm |
| RODA |
| Ban Depan |
Single, 11.00-R20-16PR |
| Ban Belakang |
Double,11.00-R20-16PR |
| SUSPENSI |
| Depan |
Multileaf |
| Belakang |
Multileaf |
| MESIN |
| Model |
6 NX1-TCS |
| Tipe |
In-Line 6 Cylinders |
| |
Direct Injection Diesel |
| |
SOHC |
| Diameter x Langkah |
115 X 125 mm |
| Isi Silinder |
7,790 cc |
| Tenaga Maksimum |
345 / 2,000 PS/rpm |
| Torsi Maksimum |
135 / 1,350 - 1,700 Kgm/rpm |
| Sistem Suplai Bahan Bakar |
Heavy Duty Commonrail |
| BERAT |
| Berat Kendaraan |
7,890 kg |
| Berat Total Kendaraan |
46,100 kg |
| TRANSMISI |
| Model |
MEB9 |
| Perbandingan Gigi |
|
| C |
10.34 |
| Gigi 1 |
7.125 |
| Gigi 2 |
5.187 |
| Gigi 3 |
3.750 |
| Gigi 4 |
2.682 |
| Gigi 5 |
1.900 |
| Gigi 6 |
1.383 |
| Gigi 7 |
1.000 |
| Gigi 8 |
0.715 |
| Rev |
9.015 |
| Perbandingan Gigi Terakhir |
5.571 |
| REM |
| Kontrol Rem |
Full Air with ABS |
| KAPASITAS GARDAN |
| Depan |
6000 |
| Belakang |
20,000 |
| LAIN-LAIN |
| Kapasitas Tangki |
200 Ltr |
| Daya Tanjak Maksimum |
30 % |
| Kecepatan Maksimum |
107 km/h |
| Aki |
12 -60 x 2 V-Ah |
| Alternator |
24-60 V-A |
| Kabin |
Wide 5 ( With Bed Space ) |
| Dimensi Rangka |
870 x 305 x 7.8 |
| Regulasi Emisi |
Euro 2 |
| Automatic Seat Belt |
Ada |
| Radio/DVD/VCD/MP3/USB |
Ada |
