| DIMENSI |
| Panjang |
5,860 mm |
|
| Lebar
| 2,485 mm |
| Tinggi |
2,920 mm |
| Jarak Sumbu |
3,560 mm |
| Julur Depan |
1,250 mm |
| Julur Belakang |
1,050 mm |
| Jarak Terendah ke Tanah |
260 mm |
| Jarak Depan |
2,060 mm |
| Jarak Belakang |
1,850 mm |
| RODA |
| Ban Depan |
Single, 10.00-R20-16PR |
| Ban Belakang |
Double,10.00-R20-16PR |
| SUSPENSI |
| Depan |
Multileaf |
| Belakang |
Multileaf |
| MESIN |
| Model |
6 HK1-TCN |
| Tipe |
In-Line 6 Cylinders |
| |
Direct Injection Diesel |
| |
OHC |
| Diameter x Langkah |
115 X 125 mm |
| Isi Silinder |
7,790 cc |
| Tenaga Maksimum |
245 / 2,400 PS/rpm |
| Torsi Maksimum |
80.5 / 1,450 – 2,400 Kgm/rpm |
| Sistem Suplai Bahan Bakar |
Heavy Duty Commonrail |
| BERAT |
| Berat Kendaraan |
5,560 kg |
| Berat Total Kendaraan |
32,700 kg |
| TRANSMISI |
| Model |
ES9306A |
| Perbandingan Gigi |
|
| C |
- |
| Gigi 1 |
9.010 |
| Gigi 2 |
5.270 |
| Gigi 3 |
3.200 |
| Gigi 4 |
2.040 |
| Gigi 5 |
1.360 |
| Gigi 6 |
1.000 |
| Rev |
8.630 |
| Perbandingan Gigi Terakhir |
5.571 |
| REM |
| Kontrol Rem |
Full Air |
| KAPASITAS GARDAN |
| Depan |
6000 |
| Belakang |
10,000 |
| LAIN-LAIN |
| Kapasitas Tangki |
200 Ltr |
| Daya Tanjak Maksimum |
18 % |
| Kecepatan Maksimum |
90 km/h |
| Aki |
12 -60 x 2 V-Ah |
| Alternator |
24-60 V-A |
| Kabin |
Wide 5 ( With Bed Space ) |
| Dimensi Rangka |
870 x 275 x 7.5 |
| Regulasi Emisi |
Euro 2 |
| Automatic Seat Belt |
Ada |
| Radio/DVD/VCD/MP3/USB |
Ada |
