| DIMENSI |
| Panjang |
6,170 mm |
|
| Lebar
| 1,835 mm |
| Tinggi |
2,170 mm |
| Jarak Sumbu |
3,360 mm |
| Julur Depan |
1,110 mm |
| Julur Belakang |
1,700 mm |
| Jarak Terendah ke Tanah |
190 mm |
| Jejak Depan |
1,490 mm |
| Jejak Belakang |
1,410 mm |
| Kapasitas Tempat Duduk |
20 orang |
| RODA |
| Ban Depan |
255 / 75 / R16 |
| Ban Belakang |
255 / 75 / R16 |
| Velg |
16" x 7.00 |
| BERAT |
| Berat Kosong Kendaraan |
1,680 kg |
| Berat Total Kendaraan |
5100 kg |
| KAPASITAS GARDAN |
| Depan |
2550 kg |
| Belakang |
2550 kg |
| MESIN |
| Model |
4JB1-TC |
| Tipe |
In-line 4 Cylinders |
| |
Direct Injection Diesel |
| |
Turbo Intercooler |
| |
OHV |
| Diameter x Langkah |
93x102 mm |
| Isi Silinder |
2,771 cc |
| Tenaga Maksimum |
100/3,400 PS/rpm |
| Torsi Maksimum |
22.5/2,000-3,200 Kgm/rpm |
| TRANSMISI |
| Model |
MSB5M |
| Perbandingan Gigi |
|
| Gigi 1 |
5.594 |
| Gigi 2 |
2.814 |
| Gigi 3 |
1.660 |
| Gigi 4 |
1.000 |
| Gigi 5 |
0.794 |
| Rev |
5.334 |
| Perbandingan Gigi Terakhir |
5.857 |
| REM |
| Rem Kaki |
hydraulic, saluran ganda dengan vacuum boster |
| Rem Tangan |
Mekanisme expanding di transmisi belakang |
| Sistem Pengereman Gas Buang |
Ada |
| SUSPENSI |
| Depan |
Semi eliptical, laminated leaf spring dengan absorber berdaya ganda |
| Belakang |
Semi eliptical, laminated leaf spring dengan absorber berdaya ganda |
| LAIN-LAIN |
| Kapasitas Tangki |
100 ltr |
| Radius Putar Minimum |
7.4 m |
| Daya Tinjak Maksimum |
29 % |
| Kecepatan Maksimum |
108 km/h |
| Aki |
12-60 V-Ah |
| Alternator |
12-60 V-A |
| Power Steering |
Ada |
| Tilt & Telescopic Steering |
Ada |
| Kamera Mundur |
Ada |
| DVD,CD,MP3,USB,Aux In, Radio |
Ada |
| Retractable Seat Belt |
Ada |
| Fan Blower |
Ada |
